WundaTrade
Multi Zone Rapid Response® Underfloor Heating Kit (Wilo Pump)
Multi Zone Rapid Response® Underfloor Heating Kit (Wilo Pump)
Shipping calculated at checkout.
Couldn't load pickup availability
Complete multi room underfloor heating kit including 20mm low profile Rapid Response® Overfloor Boards, 16mm Pert/Al/Pert Pipe, Premium Manifold, Controls, Wunda’s Premium Pumpset and Wilo Pump.
This kit features Rapid Response® Overfloor heating boards that are strong EPS with thick aluminium factory-fitted for Rapid Response® in renovations, extensions & newbuilds.
MAPEI & ULTRA approved for tiling directly onto – NO intermediate layers or levelling screed required, just prime it!
Share
Product Information
Multi Zone Rapid Response® Overfloor Heating Kit
Low Profile Rapid Response® Overfloor Heating Kits are the perfect choice for Installers wishing to install a floor heating system with no need to dig up floors or wait on wet trades.
MAPEI & ULTRA approved for tiling directly onto- NO intermediate layers or levelling screed required, just prime it!
Rapid Response® overfloor heating panels are simply stuck to the existing floor using our strong, rapid dry panel adhesive.
Multi zone kits are ideal for heating separate areas with individual thermostats, simply add more thermostats as required.
Each kit is designed to cover up to its maximum M² area with overfloor panels using Wunda Pert/Al/Pert pipe at 150mm spacing.
All kits feature 16mm high output Pert/Al/Pert pipe which contains an aluminium barrier, preventing oxygen diffusion through the pipe walls.
Rapid Response® 20mm Overfloor boards are bonded with thick Aluminium for Rapid Response® heat up times in all homes.
Our multi room kits come with a mechanical thermostat, wiring centre and actuators as standard.
|| Multi Room Size : || 40m² || 60m² || 80m² ||
| Premium Manifold | ✔ | ✔ | ✔ |
| 'A'-rated Pumpset | ✔ | ✔ | ✔ |
| Premium Thermostatic Mixing valve | ✔ | ✔ | ✔ |
| Pair of Isolation Valves | ✔ | ✔ | ✔ |
| Wiring Centre | ✔ | ✔ | ✔ |
| Actuators | 3 | 4 | 6 |
| Manual Thermostat | 1 | 1 | 1 |
| Manifold Ports | 3 | 4 | 6 |
| 16mm Pipe Lengths | 3 x 100m | 4 x 100m | 6 x 100m |
| Overfloor Heating Boards | 56 | 84 | 112 |
