Single Zone Rapid Response® Underfloor Heating Kits (Wilo Pump)
Single Zone Rapid Response® Underfloor Heating Kits (Wilo Pump)
Couldn't load pickup availability
Single zone underfloor heating kits are available in 10 area sizes from 15m² to 80m² including 20mm low profile super strong EPS Rapid Response® Overfloor Boards with thick aluminium for Rapid Response®, 16mm Pert/Al/Pert high output Pipe, Premium Manifold, Wunda’s Premium Pumpset and Wilo Pump.
MAPEI & ULTRA approved for tiling directly onto – NO intermediate layers or levelling screed required, just prime it!
Share











Product Information
Single Zone* Rapid Response Overfloor Heating Kits
Low profile Rapid Response Overfloor Heating Kits are the perfect choice for Installers wishing to install a floor heating system with no need to dig up floors or waiting on wet trades!
MAPEI & ULTRA approved for tiling directly onto- NO intermediate layers or levelling screed required! Rapid Response Overfloor Heating boards are simply stuck to the existing floor using our strong, rapid dry panel adhesive- just add the quantity required to your cart.
16mm Pert/Al/Pert high output barrier pipe can be laid straight away – no need to wait for panel adhesive to dry.
Single zone kits are ideal for heating single rooms. Each kit is designed to cover up to its maximum M² area with overfloor boards using Wunda Pert/Al/Pert pipe at 150mm spacing.
All kits feature 16mm Pert/al/Pert pipe which contains an Aluminium barrier, preventing oxygen diffusion through the pipe walls.
This kit also includes Rapid Response® 20mm low profile Super Strong EPS Overfloor board bonded with thick Aluminium for Rapid Response® heat in all homes.
Also included is the temperature control mixer valves for accurate control of water temperature.
Thermostats, controls and components can be added to suit your system requirements.
*Multi Zone Compatible All of our Single Room kits can be upgraded for Multi Room use simply by purchasing the relevant Controls and Room Thermostats.
|| Area Size || 15m² || 20m² || 25m² || 30m² || 35m² || 40m² || 50m² || 60m² || 70m² || 80m² ||
| Premium Manifold | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| 'A'-rated Pumpset | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Premium Thermostatic Mixing valve | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Pair of Isolation Valves | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Manifold Ports | 2 | 2 | 2 | 2 | 3 | 3 | 4 | 4 | 5 | 6 |
| 16mm Pipe Lengths | 1 x 100m | 2 x 80m | 2 x 100m | 2 x 100m | 3 x 80m | 3 x 100m | 4 x 100m | 4 x 100m | 5 x 100m | 6 x 100m |
| Overfloor Heating Boards | 21 | 28 | 35 | 42 | 49 | 56 | 70 | 84 | 98 | 112 |
